| PHYSICAL / MECHANICAL PROPERTIES | TRIAL METHOD | VALUE |
| Density | DIN 53479 - ISO1183 | 1,22 g/cm3 |
| Water absorption | a 23°C 50% r.h. | < 1% |
| Elongation at break | DIN 53504 - ISO37 | 500% |
| Tear resistance | DIN 53515 - ISO34 | 100 N/mm |
| Flexural elastic modulus | ASTM D790 | 120 MPa |
| Abrasion loss | DIN 53516 - ISO4649 | 30 mm3 |
| Break resistance | DIN 53504 - ISO37 | 55 MPa |
| Working temperature | - | - 40°C / +60°C |
TECHNICAL CHARACTERISTICS
Very high flexibility also at low temperature - Low sensibility to "click" and "stress cracking" effect - Excellent abrasion resistance - Good resistance to atmospheric agents - Good aging - Extremely resistance to fatigue - Excellent transparency
STANDARD MARKING:
| POLYURETHANE TRS Ø 4X6 LOT…./.... MADE IN ITALY
Marking is printed every 50 cm. Customized marking on demand.
NOTE: Tolerances according to ISO/TS 11619:2014 polyurethane tubing for use primarily in pneumatic installations.
